94‘ 3 Computerized Quilting Machines For Apparel Fabrics Sewing
Speed 400-550n/M
APPLICATIONS:
Yiboda Quilting and Embroidery Machine is widely used in car seat ,
foot pad , car pad , luggage and garment , home textile like quilts
, curtain , bed cover , etc
Function / Introduction:
1. This model comes with an infrared sensor protection device to
make the operation safer during use.
2. This type of fabric is equipped with a tension motor to ensure
the accuracy of the pattern.
3. This model can arbitrarily quilting in 360-degree pattern, and
it can quilt out the function of independent flower shape.
4. This computer system is equipped with an intelligent operation
online help prompt.
5. The actual needle speed of this model can reach up to 500
needles/min, and the needle spacing can be set arbitrarily from
2mm-6mm.
6. The actual needle speed of this model can reach up to 500
needles/min, and the needle spacing can be set arbitrarily from
2mm-6mm.
7. This model has the function of quilting pattern compensation,
which can effectively solve the problem of pattern deformation of
thick materials during quilting.
8. This model computer system is equipped with a quilted analog
display.
9. This model comes with automatic needle lifting and positioning
brake system, and the automatic stop function
Application: This machined product is widely used in bed series,
clothing fabrics, decorative items and so on.
Compare with the C series Lock stitch quilting machine:
1.Bearing with lock core, stable and not easy to heat
2.Permanent magnet inductor, less loss current, more stable pattern
3.Using synchronous belt drive, uniform rotation speed
4.Encoder program, machine information transmission more accurate
5.Adopt aviation aluminum strip, lighter material, faster machine
speed
6.Angle of fuselage for easy shuttle change
7.Cut-off auto-stop infrared data direct to the computer, the
reaction speed is faster
8.Big Four Volt Power, Faster Machine Running, up to 1000r/min
Machine Parameters:
| Mode: | 128"3Needle | 94"3Needle | 94"2Needle | 64"3Needle | 64"2Needle | | Working Width: | 3251mm | 2438mm | 2438mm | 1676mm | 1676mm | | X Area: | 305mm | 305mm | 250mm | 305mm | 250mm | | Sewing Speed: | 400-500n/m | 400-550n/m | 400-550n/m | 400-600n/m | 400-600n/m | | Quilting Design: | 360° | 360° | 360° | 360° | 360° | | Rated Voltage: | AC380V | AC380V | AC380V | AC380V | AC380V | | Voltage Deviation: | ±4% | ±4% | ±4% | ±4% | ±4% | | Power: | 5.2kw | 4.5kw | 4.5kw | 3.5kw | 3.5kw | | Machine Size: | L5700*W1300*H1700(mm) | L4800*W1300* H1700(mm) | L4800*W1300* H1700(mm) | L4800*W1300* H1700(mm) | L4800*W1300* H1700(mm) | | Container Info: | 20GP:1-2SETS, 40GP:2-4SETS | | | | |
|
High Quality Spare Parts:
Imported parts of bobbin case , rotary hook , bobbin
Linear guide
Servo Motor & Drive
YBD166 Needle distance : 50.8mm
Moving distance in X direction can reach 250mm
Quits Pattern Sample:
