YBD64-2 Industrial Computerized multi needle shuttle quilting machine for
blanket, bed spread
Features Functions:
1. New Upgrade All-in-one Type.
2. Easy loading fabric and material.
3. Computer inserted in body design. Easy to operate and maintain.
4. Automatic needle run-up and positioning brake system.
5. Operated using high quality brand bearings,high performance.
6. Auto-Stopping function once thread broken
7. digital quilting software control system allows plenty of
precise and stable quilting operations.
8. Wilcom software allows you to create your own design.
9. Machine comes with 100-300 design patterns.
10. Simulation display of quilting
11. Pattern patch-up function
Machine Parameters:
| Model Code: | YBD64-2Needles BARS |
| Fabric Working Width | 1676mm |
| X Area: | 250mm |
| Quilting Speed: | 400~600 R.P.M |
| Freedon Quilt: | 360° |
| Voltage: | AC380V |
| Voltage Deviation: | ±4% |
| Power: | 3.5kw |
| Machine Length*Width*Height: | L3800*W1300*H1700(mm) |
Working Principle
At the same time, three motors are used to drive the movement of
the XYZ axis. The X-axis controls the movement of the amine frame
to the left and right, and the Y-axis controls the movement of the
roller. The Z-axis is the main axis.
At the same time, the up-and-down movement of the needle and the
back and forth movement of the bottom bobbin are controlled to Sew
product.
Payment Term:
T/T 30% deposit from the date receipt, balance 70% by T/T before
shipment
Delivery:
within 35-40 days after received the deposit
One Year Warranty and Installation
1. Offering some free spare part when ship with the machine
2. Our machine will come with easy-to-follow, step-by-step assembly
instructions as well as a basic training CD and manual on CD
3. If required, YIBODA will send technician to your factory for
product training, installation, food, room, and ticket will
absorbed at customer's side.
4. Within a year of spare parts if any damage, the supplier free
warranty. Due to the buyer for damage and damage resulting from
force majeure is not in the scope of the warranty. (note bobbin
case, bobbin, needles, fluorescent lamp, Bobbin Winder Machine is
not in the scope of the warranty)
After-Sales Service:
1) YIBODA technician will help erect the machines and do necessary
training to customer's operators.
2.) Should any problem happened, we will give immediate and active
response, help & instruct to solve, through mall/cell phone or live
cam.
3.) Preinstalled with many patterns/designs in USB to each machine.
For new quilting patterns/designs, we will help & program at the
earliest, free of charge.
3) Normal accessories are included with machines.
4) Provide necessary operation videos for reference.
Quits Samples
